LM358DT Datasheet
Datasheet specifications
| Datasheet's name | LM358DT |
|---|---|
| File size | 69.487 KB |
| File type | |
| Number of pages | 22 |
Download Datasheet LM358DT |
Download Datasheet |
|---|
Other documentations
LM158,258,358 Datasheet 25 pages
Technical specifications
- RoHS: true
- Category: Operational Amplifier/Comparator/Operational Amplifier
- Datasheet: STMicroelectronics LM358DT
- -3db Bandwidth: -
- Output Current: 30mA
- Supply Current: 700uA
- Number of Circuits: 2
- Operating Temperature: 0°C~+70°C
- Current - Input Bias(Ib): 20nA
- Gain Bandwidth Product(GBP): 800kHz
- Package: SOP-8
- Manufacturer: STMicroelectronics
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Amplifier Type: General Purpose
- Output Type: -
- Slew Rate: 0.6V/µs
- Gain Bandwidth Product: 1.1MHz
- Current - Input Bias: 20nA
- Voltage - Input Offset: 2mV
- Current - Supply: 700µA
- Current - Output / Channel: 60mA
- Voltage - Supply, Single/Dual (±): 3V ~ 30V, ±1.5V ~ 15V
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 8-SO
- Base Part Number: LM358
- detail: General Purpose Amplifier 2 Circuit 8-SO
