TPS54332DDAR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | TPS54332DDAR |
|---|---|
| حجم فایل | 100.093 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 34 |
دانلود دیتاشیت TPS54332DDAR |
دانلود دیتاشیت |
|---|
سایر مستندات
TPS54332 35 pages
TPS54332DDAR 34 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type
- Topology: Step-down
- Datasheet: Texas Instruments TPS54332DDAR
- Output Type: Adjustable
- Input Voltage: 3.5V~28V
- Output Voltage: 0.8V~26.04V
- Number of Outputs: 1
- Switching Frequency: 1MHz
- Output Current (Max): 3.5A
- Operating Temperature: -40°C~+150°C@(TJ)
- Synchronous Rectification: NO
- Package: SOP-8-EP
- Manufacturer: Texas Instruments
- Series: Eco-Mode™
- Supplier Device Package: 8-SO PowerPad
- Voltage - Output (Min/Fixed): 0.8V
- Voltage - Input (Min): 3.5V
- Mounting Type: Surface Mount
- Output Configuration: Positive
- Package / Case: 8-PowerSOIC (0.154", 3.90mm Width)
- Voltage - Output (Max): 26.04V
- Synchronous Rectifier: No
- Base Part Number: TPS543
- Packaging: Cut Tape (CT)
- Frequency - Switching: 1MHz
- Current - Output: 3.5A
- Voltage - Input (Max): 28V
- Part Status: Active
- detail: Buck Switching Regulator IC Positive Adjustable 0.8V 1 Output 3.5A 8-PowerSOIC (0.154", 3.90mm Width)
