دیتاشیت TCA6424ARGJR

TCA6424A

مشخصات دیتاشیت

نام دیتاشیت TCA6424A
حجم فایل 1368.572 کیلوبایت
نوع فایل pdf
تعداد صفحات 36

دانلود دیتاشیت TCA6424A

TCA6424A Datasheet

مشخصات

  • RoHS: true
  • Category: Communication Interface Chip/UART/485/232/I/O Expanders
  • Datasheet: Texas Instruments TCA6424ARGJR
  • Interface: I2C;SMBus
  • Output Type: Push-pull
  • Number of I/O: 24
  • Supply Voltage: 1.65V~5.5V
  • Clock Frequency: 400kHz
  • Interrupt Output: 有中断输出
  • Output Sink Current: 25mA
  • Operating Temperature: -40°C~+85°C
  • Output Source current: 10mA
  • Package: QFN-32-EP(5x5)
  • Manufacturer: Texas Instruments
  • Base Part Number: TCA642
  • Features: POR
  • Current - Output Source/Sink: 10mA, 25mA
  • Packaging: Cut Tape (CT)
  • Supplier Device Package: 32-UQFN-EP (5x5)
  • Voltage - Supply: 1.65V ~ 5.5V
  • Part Status: Active
  • Series: -
  • Mounting Type: Surface Mount
  • Package / Case: 32-UFQFN Exposed Pad
  • detail: I/O Expander 24 I²C, SMBus 400kHz 32-UQFN-EP (5x5)
