دیتاشیت 2N1613
مشخصات دیتاشیت
| نام دیتاشیت |
2N1613, 2N1711
|
| حجم فایل |
63.028
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
5
|
مشخصات
-
Manufacturer:
STMicroelectronics
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Obsolete
-
Transistor Type:
NPN
-
Current - Collector (Ic) (Max):
500mA
-
Voltage - Collector Emitter Breakdown (Max):
50V
-
Vce Saturation (Max) @ Ib, Ic:
1.5V @ 15mA, 150mA
-
Current - Collector Cutoff (Max):
10nA (ICBO)
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
40 @ 150mA, 10V
-
Power - Max:
800mW
-
Frequency - Transition:
80MHz
-
Operating Temperature:
-65°C ~ 200°C (TJ)
-
Mounting Type:
Through Hole
-
Package / Case:
TO-205AD, TO-39-3 Metal Can
-
Supplier Device Package:
TO-39
-
Base Part Number:
2N16
-
detail:
Bipolar (BJT) Transistor NPN 50V 500mA 80MHz 800mW Through Hole TO-39
