دیتاشیت 2N2369A
مشخصات دیتاشیت
| نام دیتاشیت |
2N2369A
|
| حجم فایل |
97.637
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
6
|
مشخصات
-
Manufacturer:
STMicroelectronics
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Obsolete
-
Transistor Type:
NPN
-
Current - Collector (Ic) (Max):
200mA
-
Voltage - Collector Emitter Breakdown (Max):
15V
-
Vce Saturation (Max) @ Ib, Ic:
500mV @ 10mA, 100mA
-
Current - Collector Cutoff (Max):
400nA
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
40 @ 10mA, 1V
-
Power - Max:
360mW
-
Frequency - Transition:
675MHz
-
Operating Temperature:
-65°C ~ 200°C (TJ)
-
Mounting Type:
Through Hole
-
Package / Case:
TO-206AA, TO-18-3 Metal Can
-
Supplier Device Package:
TO-18
-
Base Part Number:
2N23
