دیتاشیت MMBF170LT1G

MMBF170LT1

مشخصات دیتاشیت

نام دیتاشیت MMBF170LT1
حجم فایل 117.709 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

دانلود دیتاشیت MMBF170LT1

MMBF170LT1 Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 60V
  • Current - Continuous Drain (Id) @ 25°C: 500mA (Ta)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 5Ohm @ 200mA, 10V
  • Vgs(th) (Max) @ Id: 3V @ 1mA
  • Vgs (Max): ±20V
  • Input Capacitance (Ciss) (Max) @ Vds: 60pF @ 10V
  • FET Feature: -
  • Power Dissipation (Max): 225mW (Ta)
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Surface Mount
  • Supplier Device Package: SOT-23-3 (TO-236)
  • Package / Case: TO-236-3, SC-59, SOT-23-3
  • Base Part Number: MMBF17
  • detail: N-Channel 60V 500mA (Ta) 225mW (Ta) Surface Mount SOT-23-3 (TO-236)
