دیتاشیت SN74LS74AN
مشخصات دیتاشیت
| نام دیتاشیت | SN54,74(LS,S)74(A) |
|---|---|
| حجم فایل | 1420.455 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 24 |
دانلود دیتاشیت SN54,74(LS,S)74(A) |
SN54,74(LS,S)74(A) Datasheet |
|---|
مشخصات
- RoHS: true
- Type: D-Type
- Series: 74LS
- Category: Logic ICs/Flip Flops
- Function: 置位和复位
- Datasheet: Texas Instruments SN74LS74AN
- Output Type: 互补型
- Sink Current: 8mA
- Trigger Type: 上升沿
- Source Current: 400uA
- Supply Voltage: 4.75V~5.25V
- Clock Frequency: 33MHz
- Input Capacitance: -
- Number of Elements: 2
- Operating Temperature: 0°C~+70°C
- Quiescent Current (Iq): 8mA
- Maximum Propagation Delay: 25ns@2.5V,15pF
- Number of Bits per Element: 1
- Package: PDIP-14
- Manufacturer: Texas Instruments
- Voltage - Supply: 4.75V ~ 5.25V
- Package / Case: 14-DIP (0.300", 7.62mm)
- Packaging: Tube
- Current - Output High, Low: 400µA, 8mA
- Part Status: Active
- Base Part Number: SN74LS74
- Supplier Device Package: 14-PDIP
- Mounting Type: Through Hole
- Current - Quiescent (Iq): 8mA
- Max Propagation Delay @ V, Max CL: 25ns @ 2.5V, 15pF
- detail: Flip Flop 2 Element D-Type 1 Bit Positive Edge 14-DIP (0.300", 7.62mm)
