STPS40120CT 数据手册
其他文档
STPS40120C 11 pages
技术规格
- RoHS: true
- Category: Diodes/Schottky Barrier Diodes (SBD)
- Datasheet: STMicroelectronics STPS40120CT
- Diode Configuration: Dual Common Cathode
- Reverse Voltage (Vr): 120V
- Forward Voltage (Vf@If): 900mV@20A
- Reverse Leakage Current (Ir): 25uA@120V
- Average Rectified Current (Io): 20A
- Package: TO-220
- Manufacturer: STMicroelectronics
- Series: -
- Packaging: Tube
- Part Status: Active
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 120V
- Current - Average Rectified (Io) (per Diode): 20A
- Voltage - Forward (Vf) (Max) @ If: 900mV @ 20A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Current - Reverse Leakage @ Vr: 25µA @ 120V
- Operating Temperature - Junction: 175°C (Max)
- Mounting Type: Through Hole
- Package / Case: TO-220-3
- Supplier Device Package: TO-220AB
- Base Part Number: STPS401
- detail: Diode Array 1 Pair Common Cathode Schottky 120V 20A Through Hole TO-220-3
