دیتاشیت STTH2003CT

STTH2003

مشخصات دیتاشیت

نام دیتاشیت STTH2003
حجم فایل 373.375 کیلوبایت
نوع فایل pdf
تعداد صفحات 16

دانلود دیتاشیت STTH2003

STTH2003 Datasheet

مشخصات

  • RoHS: true
  • Category: Diodes/Diodes - Fast Recovery Rectifiers
  • Datasheet: STMicroelectronics STTH2003CT
  • Diode Configuration: Dual Common Cathode
  • Reverse Voltage (Vr): 300V
  • Operating Temperature: +175°C@(Tj)
  • Forward Voltage (Vf@If): 1.25V@10A
  • Reverse Leakage Current: 20uA@300V
  • Reverse Recovery Time (trr): 35ns
  • Average Rectified Current (Io): 10A
  • Package: TO-220
  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 300V
  • Current - Average Rectified (Io) (per Diode): 10A
  • Voltage - Forward (Vf) (Max) @ If: 1.25V @ 10A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 20µA @ 300V
  • Operating Temperature - Junction: 175°C (Max)
  • Mounting Type: Through Hole
  • Package / Case: TO-220-3
  • Supplier Device Package: TO-220AB
  • Base Part Number: STTH2
