دیتاشیت STN3PF06

STN3PF06

مشخصات دیتاشیت

نام دیتاشیت STN3PF06
حجم فایل 210.933 کیلوبایت
نوع فایل pdf
تعداد صفحات 9

دانلود دیتاشیت STN3PF06

STN3PF06 Datasheet

مشخصات

  • Manufacturer: STMicroelectronics
  • Series: STripFET™ II
  • Packaging: Cut Tape (CT)
  • Part Status: Obsolete
  • FET Type: P-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 60V
  • Current - Continuous Drain (Id) @ 25°C: 2.5A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 220mOhm @ 1.5A, 10V
  • Vgs(th) (Max) @ Id: 4V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 21nC @ 10V
  • Vgs (Max): ±20V
  • Input Capacitance (Ciss) (Max) @ Vds: 850pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 2.5W (Tc)
  • Operating Temperature: -65°C ~ 150°C (TJ)
  • Mounting Type: Surface Mount
  • Supplier Device Package: SOT-223
  • Package / Case: TO-261-4, TO-261AA
  • Base Part Number: STN3P
  • detail: P-Channel 60V 2.5A (Tc) 2.5W (Tc) Surface Mount SOT-223
