دیتاشیت UC2843AD
مشخصات دیتاشیت
| نام دیتاشیت | UC1842A-45A, UC2842A-45A, UC3842A-45A |
|---|---|
| حجم فایل | 2740.887 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 50 |
دانلود دیتاشیت UC1842A-45A, UC2842A-45A, UC3842A-45A |
UC1842A-45A, UC2842A-45A, UC3842A-45A Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/AC-DC Controllers & Regulators
- Datasheet: Texas Instruments UC2843AD
- Supply Voltage: 7.6V~30V
- Operating Temperature: -40°C~+85°C@(TA)
- Package: SOP-14
- Manufacturer: Texas Instruments
- Output Phases: 1
- Series: -
- Output Configuration: Positive
- Output Type: Transistor Driver
- Clock Sync: No
- Topology: Boost, Buck, Buck-Boost, Flyback, Forward
- Packaging: Tube
- Synchronous Rectifier: No
- Voltage - Supply (Vcc/Vdd): 7.6V ~ 30V
- Function: Step-Up, Step-Down, Step-Up/Step-Down
- Supplier Device Package: 14-SOIC
- Duty Cycle (Max): 96%
- Serial Interfaces: -
- Frequency - Switching: Up to 500kHz
- Mounting Type: Surface Mount
- Base Part Number: UC2843
- Number of Outputs: 1
- Part Status: Active
- Control Features: Frequency Control
- Package / Case: 14-SOIC (0.154", 3.90mm Width)
