دیتاشیت L292

L292

مشخصات دیتاشیت

نام دیتاشیت L292
حجم فایل 210.088 کیلوبایت
نوع فایل pdf
تعداد صفحات 13

دانلود دیتاشیت L292

L292 Datasheet

مشخصات

  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Motor Type - Stepper: -
  • Motor Type - AC, DC: Brushed DC
  • Function: Driver - Fully Integrated, Control and Power Stage
  • Output Configuration: Half Bridge (2)
  • Interface: Parallel
  • Technology: Bipolar
  • Step Resolution: -
  • Applications: General Purpose
  • Current - Output: 2A
  • Voltage - Supply: 18V ~ 36V
  • Voltage - Load: 18V ~ 36V
  • Operating Temperature: -40°C ~ 150°C (TJ)
  • Mounting Type: Through Hole
  • Package / Case: 15-SSIP Exposed Pad, Formed Leads
  • Supplier Device Package: 15-Multiwatt
  • Base Part Number: L292
  • detail: Motor Driver Bipolar Parallel 15-Multiwatt
