دیتاشیت SN74ALS1004N
مشخصات دیتاشیت
| نام دیتاشیت | SN54/74(ALS,AS)1004(A) |
|---|---|
| حجم فایل | 966.147 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 20 |
دانلود دیتاشیت SN54/74(ALS,AS)1004(A) |
SN54/74(ALS,AS)1004(A) Datasheet |
|---|
مشخصات
- Voltage - Supply: 4.5V ~ 5.5V
- Logic Level - Low: 0.8V
- Number of Circuits: 6
- Package / Case: 14-DIP (0.300", 7.62mm)
- Series: 74ALS
- Max Propagation Delay @ V, Max CL: 7ns @ 5V, 50pF
- Number of Inputs: 6
- Base Part Number: SN74ALS1
- Mounting Type: Through Hole
- Current - Quiescent (Max): 3mA
- Supplier Device Package: 14-PDIP
- Logic Type: Inverter
- Packaging: Tube
- Manufacturer: Texas Instruments
- Operating Temperature: 0°C ~ 70°C
- Features: -
- Current - Output High, Low: 15mA, 24mA
- Part Status: Active
- Logic Level - High: 2V
