دیتاشیت BSS123

BSS123 Datasheet

مشخصات دیتاشیت

نام دیتاشیت BSS123 Datasheet
حجم فایل 278.033 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

دانلود دیتاشیت BSS123 Datasheet

BSS123 Datasheet Datasheet

مشخصات

  • RoHS: true
  • Type: N Channel
  • Category: Triode/MOS Tube/Transistor/MOSFETs
  • Datasheet: AnBon BSS123
  • Power Dissipation (Pd): 350mW
  • Total Gate Charge (Qg@Vgs): 1.8nC@10V
  • Drain Source Voltage (Vdss): 100V
  • Input Capacitance (Ciss@Vds): 14pF@50V
  • Continuous Drain Current (Id): 200mA
  • Gate Threshold Voltage (Vgs(th)@Id): 2.5V@250uA
  • Drain Source On Resistance (RDS(on)@Vgs,Id): 5Ω@10V,200mA
  • Package: SOT-23
  • Manufacturer: AnBon
  • Operating Temperature: -50°C~+150°C@(Tj)
  • Reverse Transfer Capacitance (Crss@Vds): -
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 100V
  • Current - Continuous Drain (Id) @ 25°C: 170mA (Ta)
  • Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
  • Rds On (Max) @ Id, Vgs: 6Ohm @ 170mA, 10V
  • Vgs(th) (Max) @ Id: 2V @ 1mA
  • Gate Charge (Qg) (Max) @ Vgs: 2.5nC @ 10V
  • Vgs (Max): ±20V
  • Input Capacitance (Ciss) (Max) @ Vds: 73pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 360mW (Ta)
  • Mounting Type: Surface Mount
  • Supplier Device Package: SOT-23-3
  • Package / Case: TO-236-3, SC-59, SOT-23-3
  • Base Part Number: BSS123
