دیتاشیت UCC21520DWR

UCC21520 Datasheet

مشخصات دیتاشیت

نام دیتاشیت UCC21520 Datasheet
حجم فایل 2503.873 کیلوبایت
نوع فایل pdf
تعداد صفحات 52

دانلود دیتاشیت UCC21520 Datasheet

UCC21520 Datasheet Datasheet

مشخصات

  • Base Part Number: UCC215
  • Approval Agency: CQC, CSA, UR, VDE
  • Number of Channels: 2
  • Rise / Fall Time (Typ): 6ns, 7ns
  • Supplier Device Package: 16-SOIC
  • Current - Peak Output: -
  • Operating Temperature: -40°C ~ 125°C
  • Common Mode Transient Immunity (Min): 100V/ns
  • Packaging: Cut Tape (CT)
  • Pulse Width Distortion (Max): 5ns
  • Voltage - Output Supply: 6.5V ~ 25V
  • Part Status: Active
  • Manufacturer: Texas Instruments
  • Series: -
  • Propagation Delay tpLH / tpHL (Max): 30ns, 30ns
  • Mounting Type: Surface Mount
  • Package / Case: 16-SOIC (0.295", 7.50mm Width)
  • Voltage - Forward (Vf) (Typ): -
  • Voltage - Isolation: 5700Vrms
  • Technology: Capacitive Coupling
  • Current - Output High, Low: 4A, 6A
