STTH6002CW دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | STTH6002CW |
|---|---|
| حجم فایل | 48.445 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 9 |
دانلود دیتاشیت STTH6002CW |
دانلود دیتاشیت |
|---|
سایر مستندات
STTH6002C 9 pages
STTH6002CW 5 pages
مشخصات فنی
- RoHS: true
- Category: Diodes/Diodes - Fast Recovery Rectifiers
- Datasheet: STMicroelectronics STTH6002CW
- Diode Configuration: Dual Common Cathode
- Reverse Voltage (Vr): 200V
- Operating Temperature: +175°C@(Tj)
- Forward Voltage (Vf@If): 1.05V@30A
- Reverse Leakage Current: 30uA@200V
- Reverse Recovery Time (trr): 22ns
- Average Rectified Current (Io): 30A
- Package: TO-247
- Manufacturer: STMicroelectronics
- Series: -
- Packaging: Tube
- Part Status: Active
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 200V
- Current - Average Rectified (Io) (per Diode): 30A
- Voltage - Forward (Vf) (Max) @ If: 1.05V @ 30A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Current - Reverse Leakage @ Vr: 30µA @ 200V
- Operating Temperature - Junction: 175°C (Max)
- Mounting Type: Through Hole
- Package / Case: TO-247-3
- Supplier Device Package: TO-247-3
- Base Part Number: STTH6002
