دیتاشیت SG2526BDW

مشخصات دیتاشیت

دانلود دیتاشیت SG1526B,2526B,3526B	SG1526B,2526B,3526B Datasheet

Manufacturer: Microchip Technology
Series: -
Packaging: -
Part Status: Discontinued at Digi-Key
Output Type: Transistor Driver
Function: Step-Down, Step-Up/Step-Down
Output Configuration: Positive
Topology: Buck, Flyback
Number of Outputs: 2
Output Phases: 1
Voltage - Supply (Vcc/Vdd): 8V ~ 35V
Frequency - Switching: 1Hz ~ 500kHz
Duty Cycle (Max): 49%
Synchronous Rectifier: Yes
Clock Sync: No
Serial Interfaces: -
Control Features: Dead Time Control, Enable, Frequency Control, Reset, Soft Start
Operating Temperature: -25°C ~ 85°C (TA)
Mounting Type: Surface Mount
Package / Case: 18-SOIC (0.295", 7.50mm Width)
Supplier Device Package: 18-SOIC
Base Part Number: SG*526
detail: Buck, Flyback Regulator Positive Output Step-Down, Step-Up/Step-Down DC-DC Controller IC 18-SOIC
