دیتاشیت MC33172DR2G
مشخصات دیتاشیت
| نام دیتاشیت | MC33171(72,74), NCV33172 |
|---|---|
| حجم فایل | 173.82 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 15 |
دانلود دیتاشیت MC33171(72,74), NCV33172 |
MC33171(72,74), NCV33172 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Operational Amplifier/Comparator/Operational Amplifier
- Datasheet: onsemi MC33172DR2G
- -3db Bandwidth: -
- Output Current: 27mA
- Supply Current: 220uA
- Number of Circuits: 2
- Operating Temperature: -40°C~+85°C
- Current - Input Bias(Ib): 20nA
- Gain Bandwidth Product(GBP): 1.8MHz
- Package: SOP-8
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Obsolete
- Amplifier Type: General Purpose
- Output Type: -
- Slew Rate: 2.1V/µs
- Gain Bandwidth Product: 1.8MHz
- Current - Input Bias: 20nA
- Voltage - Input Offset: 2mV
- Current - Supply: 220µA
- Current - Output / Channel: 27mA
- Voltage - Supply, Single/Dual (±): 3V ~ 44V, ±1.5V ~ 22V
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 8-SOIC
- Base Part Number: MC33172
- detail: General Purpose Amplifier 2 Circuit 8-SOIC
