دیتاشیت 74AC138SC
مشخصات دیتاشیت
| نام دیتاشیت | 74AC138, 74ACT138 |
|---|---|
| حجم فایل | 225.416 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 11 |
دانلود دیتاشیت 74AC138, 74ACT138 |
74AC138, 74ACT138 Datasheet |
|---|
مشخصات
- RoHS: true
- Type: Decoder/Demultiplexers
- Category: Logic ICs/Signal Switches / Encoders & Decoders / Multiplexers
- Datasheet: onsemi 74AC138SC
- Sink Current: 24mA
- Source Current: 24mA
- Supply Voltage: 2V~6V
- Operating temperature: -40°C~+85°C
- Voltage Supply Source: Single supply
- Package: SOP-16
- Manufacturer: onsemi
- Series: 74AC
- Packaging: Tube
- Part Status: Active
- Circuit: 1 x 3:8
- Independent Circuits: 1
- Current - Output High, Low: 24mA, 24mA
- Voltage - Supply: 2V ~ 6V
- Mounting Type: Surface Mount
- Package / Case: 16-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 16-SOIC
- Base Part Number: 74AC138
- detail: Decoder/Demultiplexer 1 x 3:8 16-SOIC
