دیتاشیت MMBTA92
مشخصات دیتاشیت
| نام دیتاشیت |
MMBTA92
|
| حجم فایل |
377.721
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
9
|
مشخصات
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
-
Datasheet:
ST(Semtech) MMBTA92
-
Transistor Type:
PNP
-
Operating Temperature:
+150°C@(Tj)
-
Collector Current (Ic):
500mA
-
Power Dissipation (Pd):
350mW
-
Transition Frequency (fT):
50MHz
-
DC Current Gain (hFE@Ic,Vce):
80@10mA,10V
-
Collector Cut-Off Current (Icbo):
250nA
-
Collector-Emitter Breakdown Voltage (Vceo):
300V
-
Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib):
500mV@20mA,2mA
-
Package:
SOT-23
-
Manufacturer:
ST(Semtech)
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
Current - Collector (Ic) (Max):
500mA
-
Voltage - Collector Emitter Breakdown (Max):
300V
-
Vce Saturation (Max) @ Ib, Ic:
500mV @ 2mA, 20mA
-
Current - Collector Cutoff (Max):
100nA (ICBO)
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
40 @ 30mA, 10V
-
Power - Max:
350mW
-
Frequency - Transition:
50MHz
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-236-3, SC-59, SOT-23-3
-
Supplier Device Package:
SOT-23-3
-
Base Part Number:
MMBT
-
detail:
Bipolar (BJT) Transistor PNP 300V 500mA 50MHz 350mW Surface Mount SOT-23-3
