- دیتاشیت ISO7241CDWR
ISO7241CDWR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | ISO7241CDWR |
|---|---|
| حجم فایل | 101.57 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 40 |
دانلود دیتاشیت ISO7241CDWR |
دانلود دیتاشیت |
|---|
سایر مستندات
ISO7240CF, ISO7240-42C/M 44 pages
مشخصات فنی
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Digital Isolators
- Data Rate: 25Mbps
- Datasheet: Texas Instruments ISO7241CDWR
- Applications: General-purpose
- Supply Voltage: 3.15V~5.5V
- Forward Channel: 3
- Reverse channel: 1
- Number of Channels: 4
- Isolation Technology: 电容隔离
- Operating Temperature: -40°C~+125°C
- Voltage Isolation or Not: 带电压隔离
- Package: SOP-16-300mil
- Manufacturer: Texas Instruments
- Inputs - Side 1/Side 2: 3/1
- Package / Case: 16-SOIC (0.295", 7.50mm Width)
- Rise / Fall Time (Typ): 2ns, 2ns
- Type: General Purpose
- Packaging: Cut Tape (CT)
- Supplier Device Package: 16-SOIC
- Part Status: Active
- Common Mode Transient Immunity (Min): 25kV/µs
- Base Part Number: ISO7241
- Pulse Width Distortion (Max): 2.5ns
- Isolated Power: No
- Channel Type: Unidirectional
- Voltage - Supply: 3.15V ~ 5.5V
- Series: -
- Propagation Delay tpLH / tpHL (Max): 42ns, 42ns
- Mounting Type: Surface Mount
- Voltage - Isolation: 2500Vrms
- Technology: Capacitive Coupling
