INA220BIDGST Datasheet
Datasheet specifications
| Datasheet's name | INA220BIDGST |
|---|---|
| File size | 76.85 KB |
| File type | |
| Number of pages | 39 |
Download Datasheet INA220BIDGST |
Download Datasheet |
|---|
Other documentations
Analog Signal Chain Guide 11 pages
INA220 41 pages
Technical specifications
- RoHS: true
- Category: Power Supply Chip/Monitors & Reset Circuits
- Datasheet: Texas Instruments INA220BIDGST
- Package: MSOP-10
- Manufacturer: Texas Instruments
- Current - Output: 10mA
- Series: -
- Operating Temperature: -40°C ~ 125°C
- Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
- Function: Current Monitor
- Packaging: Cut Tape (CT)
- Sensing Method: High/Low-Side
- Part Status: Active
- Base Part Number: INA220
- Supplier Device Package: 10-VSSOP
- Mounting Type: Surface Mount
- Accuracy: ±0.5%
- Voltage - Input: 0V ~ 26V
