Power Management Guide Datasheet

Power Management Guide

Datasheet specifications

Datasheet's name Power Management Guide
File size 6420.273 KB
File type pdf
Number of pages 93

Download Datasheet Power Management Guide

Download Datasheet

Other documentations

UC1875-78, UC2875-78, UC3875-78 22 pages

UC2875DWP 23 pages

Technical specifications

  • RoHS: true
  • Category: Power Supply Chip/AC-DC Controllers & Regulators
  • Topology: Full-Bridge
  • Datasheet: Texas Instruments UC3875N
  • Duty Cycle: 100%
  • Supply Voltage: 9.5V~20V
  • Output Isolation: Non-Insulated
  • Switching Frequency: 1MHz
  • Operating Temperature: 0°C~+70°C@(Ta)
  • Package: PDIP-20
  • Manufacturer: Texas Instruments
  • Frequency - Switching: 1MHz
  • Part Status: Active
  • Package / Case: 20-DIP (0.300", 7.62mm)
  • Packaging: Tube
  • Internal Switch(s): -
  • Fault Protection: Current Limiting
  • Voltage - Breakdown: -
  • Series: -
  • Control Features: Frequency Control, Soft Start, Sync
  • Supplier Device Package: 20-PDIP
  • Mounting Type: Through Hole
  • Base Part Number: UC387
  • Voltage - Supply (Vcc/Vdd): 9.5V ~ 20V
  • Voltage - Start Up: 10.75V
