دیتاشیت SN74HC157DBR
مشخصات دیتاشیت
| نام دیتاشیت | SN54HC157, SN74HC157 |
|---|---|
| حجم فایل | 1241.659 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 22 |
دانلود دیتاشیت SN54HC157, SN74HC157 |
SN54HC157, SN74HC157 Datasheet |
|---|
مشخصات
- RoHS: true
- Type: Multiplexers
- Category: Logic ICs/Signal Switches / Encoders & Decoders / Multiplexers
- Datasheet: Texas Instruments SN74HC157DBR
- Sink Current: 7.8mA
- Source Current: 7.8mA
- Supply Voltage: 2V~6V
- Operating temperature: -40°C~+85°C
- Voltage Supply Source: Single supply
- Package: SSOP-16
- Manufacturer: Texas Instruments
- Supplier Device Package: 16-SSOP
- Current - Output High, Low: 7.8mA, 7.8mA
- Circuit: 4 x 2:1
- Mounting Type: Surface Mount
- Base Part Number: SN74HC1
- Packaging: Cut Tape (CT)
- Series: 74HC
- Independent Circuits: 1
- Part Status: Active
- Package / Case: 16-SSOP (0.209", 5.30mm Width)
- Voltage - Supply: 2V ~ 6V
- detail: Multiplexer 4 x 2:1 16-SSOP
