دیتاشیت ESDA5V3SC6

ESDAxxSCx

مشخصات دیتاشیت

نام دیتاشیت ESDAxxSCx
حجم فایل 312.968 کیلوبایت
نوع فایل pdf
تعداد صفحات 9

دانلود دیتاشیت ESDAxxSCx

ESDAxxSCx Datasheet

مشخصات

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
  • Polarity: Unidirectional
  • Datasheet: STMicroelectronics ESDA5V3SC6
  • Number of Lines: 4
  • Clamping Voltage@Ipp: 21V
  • Operating Temperature: -40°C~+125°C@(Ta)
  • Breakdown Voltage (VBR): 5.3V
  • Peak Pulse Power(Ppp)@8/20us: 500W
  • Junction Capacitance(Cj)@1MHz: -
  • Peak Pulse Current(Ipp)@8/20us: 22A
  • Reverse Stand-Off Voltage (Vrwm): 3V
  • Package: SOT-23-6
  • Manufacturer: STMicroelectronics
  • Series: ESDA, TRANSIL™
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: Zener
  • Unidirectional Channels: 4
  • Voltage - Reverse Standoff (Typ): 3V
  • Voltage - Breakdown (Min): 5.3V
  • Voltage - Clamping (Max) @ Ipp: -
  • Current - Peak Pulse (10/1000µs): -
  • Power - Peak Pulse: 500W
  • Power Line Protection: No
  • Applications: General Purpose
  • Capacitance @ Frequency: -
  • Mounting Type: Surface Mount
  • Package / Case: SOT-23-6
  • Supplier Device Package: SOT-23-6
  • Base Part Number: ESDA5
