LR8K4-G 数据手册
其他文档
LR8 18 pages
技术规格
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Microchip Tech LR8K4-G
- Output Type: Adjustable
- Output Current: 10mA
- Output Voltage: 1.2V~438V
- Dropout Voltage: -
- Output Polarity: Positive
- Number of Outputs: 1
- Maximum Input Voltage: 450V
- Operating Temperature: -40°C~+85°C
- Power Supply Rejection Ratio (PSRR): 60dB@(120Hz)
- Package: TO-252-2(DPAK)
- Manufacturer: Microchip Tech
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Configuration: Positive
- Number of Regulators: 1
- Voltage - Input (Max): 450V
- Voltage - Output (Min/Fixed): 1.2V
- Voltage - Output (Max): 438V
- Voltage Dropout (Max): -
- Current - Output: 10mA
- PSRR: 60dB (120Hz)
- Control Features: -
- Protection Features: Over Current, Over Temperature
- Mounting Type: Surface Mount
- Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Supplier Device Package: TO-252, (D-Pak)
- Base Part Number: LR8
- detail: Linear Voltage Regulator IC 1 Output 10mA TO-252, (D-Pak)
