دیتاشیت MIC29302WU-TR

مشخصات دیتاشیت

MIC29302WU-TR	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/Linear Voltage Regulators (LDO)
Datasheet: Microchip Tech MIC29302WU-TR
Output Type: Adjustable
Output Current: 3A
Output Voltage: 1.25V~25V
Dropout Voltage: 600mV@(3A)
Output Polarity: Positive
Number of Outputs: 1
Maximum Input Voltage: 26V
Operating Temperature: -40°C~+125°C
Power Supply Rejection Ratio (PSRR): -
Package: TO-263-5
Manufacturer: Microchip Tech
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Output Configuration: Positive
Number of Regulators: 1
Voltage - Input (Max): 26V
Voltage - Output (Min/Fixed): 1.25V
Voltage - Output (Max): 25V
Voltage Dropout (Max): 0.6V @ 3A
Current - Output: 3A
PSRR: -
Control Features: Enable
Protection Features: Over Current, Over Temperature, Reverse Polarity, Transient Voltage
Mounting Type: Surface Mount
Package / Case: TO-263-6, D²Pak (5 Leads + Tab), TO-263BA
Supplier Device Package: TO-263-5
Base Part Number: MIC29302
detail: Linear Voltage Regulator IC 1 Output 3A TO-263-5
