دیتاشیت AD7864ASZ-1

AD7864

مشخصات دیتاشیت

نام دیتاشیت AD7864
حجم فایل 771.914 کیلوبایت
نوع فایل pdf
تعداد صفحات 28

دانلود دیتاشیت AD7864

AD7864 Datasheet

مشخصات

  • Manufacturer: Analog Devices Inc.
  • Series: -
  • Packaging: Tray
  • Part Status: Active
  • Number of Bits: 12
  • Sampling Rate (Per Second): 520k
  • Number of Inputs: 4
  • Input Type: Single Ended
  • Data Interface: Parallel
  • Configuration: S/H-MUX-ADC
  • Ratio - S/H:ADC: 4:1
  • Number of A/D Converters: 1
  • Architecture: SAR
  • Reference Type: External, Internal
  • Voltage - Supply, Analog: 5V
  • Voltage - Supply, Digital: 5V
  • Features: Simultaneous Sampling
  • Operating Temperature: -40°C ~ 85°C
  • Package / Case: 44-QFP
  • Supplier Device Package: 44-MQFP (10x10)
  • Mounting Type: Surface Mount
  • Base Part Number: AD7864
  • detail: 12 Bit Analog to Digital Converter 4 Input 1 SAR 44-MQFP (10x10)
