دیتاشیت TMS320F28026FPTT
مشخصات دیتاشیت
| نام دیتاشیت |
TMS320F2802x0
|
| حجم فایل |
2396.58
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
139
|
مشخصات
-
RoHS:
true
-
CPU Core:
C28x
-
Category:
Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
-
RAM Size:
12KB
-
ADC (Bit):
12bit
-
Datasheet:
Texas Instruments TMS320F28026FPTT
-
CPU Maximum Speed:
60MHz
-
GPIO Ports Number:
22
-
Internal Oscillator:
Yes
-
Direct Memory Access:
-
-
Universal Serial Bus:
-
-
Operating Voltage Range:
1.71V~1.995V
-
Operating Temperature Range:
-40°C~+105°C
-
Package:
LQFP-48(7x7)
-
Manufacturer:
Texas Instruments
-
Peripherals:
Brown-out Detect/Reset, POR, PWM, WDT
-
Voltage - Supply (Vcc/Vdd):
1.71V ~ 1.995V
-
Base Part Number:
TMS320
-
Speed:
60MHz
-
Package / Case:
48-LQFP
-
Program Memory Type:
FLASH
-
EEPROM Size:
-
-
Supplier Device Package:
48-LQFP (7x7)
-
Series:
C2000™ C28x Piccolo™
-
Operating Temperature:
-40°C ~ 105°C (TA)
-
Number of I/O:
22
-
Oscillator Type:
Internal
-
Part Status:
Active
-
Mounting Type:
Surface Mount
-
Core Size:
32-Bit
-
Connectivity:
I²C, SCI, SPI, UART/USART
-
Program Memory Size:
32KB (16K x 16)
-
Core Processor:
C28x
-
Packaging:
Tray
-
Data Converters:
A/D 13x12b
-
detail:
C28x C2000™ C28x Piccolo™ Microcontroller IC 32-Bit 60MHz 32KB (16K x 16) FLASH 48-LQFP (7x7)
