دیتاشیت UCC2807D-3

مشخصات دیتاشیت

دانلود دیتاشیت UCC1807, 2807, 3807 -1/- 2/-3	UCC1807, 2807, 3807 -1/- 2/-3 Datasheet

RoHS: true
Category: Power Supply Chip/DC-DC Controllers
Function: Buck-boost type
Topology: Boost;Flyback;Forward
Datasheet: Texas Instruments UCC2807D-3
Input Voltage: 4.1V~13.5V
Duty Cycle (Max): 78%
Number of Outputs: 1
Switching Frequency: 202kHz
Operating Temperature: -40°C~+85°C@(TA)
Synchronous Rectification: NO
Package: SOP-8
Manufacturer: Texas Instruments
Voltage - Supply (Vcc/Vdd): 4.1V ~ 13.5V
Base Part Number: UCC280
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Output Configuration: Positive
Series: -
Supplier Device Package: 8-SOIC
Frequency - Switching: 202kHz
Part Status: Active
Mounting Type: Surface Mount
Control Features: -
Clock Sync: No
Serial Interfaces: -
Packaging: Tube
Synchronous Rectifier: No
Output Type: Transistor Driver
Output Phases: 1
detail: Boost, Flyback, Forward Converter Regulator Positive Output Step-Up, Step-Up/Step-Down DC-DC Controller IC 8-SOIC
