LM2587T-ADJ 数据手册
其他文档
LM2587 39 pages
技术规格
- Series: SIMPLE SWITCHER®
- Topology: Boost, Flyback, Forward Converter
- Voltage - Input (Min): 4V
- Base Part Number: LM2587
- Function: Step-Up, Step-Up/Step-Down
- Current - Output: 5A (Switch)
- Frequency - Switching: 100kHz
- Part Status: Not For New Designs
- Voltage - Input (Max): 40V
- Mounting Type: Through Hole
- Supplier Device Package: TO-220-5
- Operating Temperature: -40°C ~ 125°C (TJ)
- Voltage - Output (Min/Fixed): 1.23V
- Manufacturer: Texas Instruments
- Package / Case: TO-220-5 Formed Leads
- Voltage - Output (Max): 60V
- Packaging: Tube
- Output Configuration: Positive
- Synchronous Rectifier: No
- Output Type: Adjustable
- Number of Outputs: 1
