دیتاشیت LM2903DR
مشخصات دیتاشیت
| نام دیتاشیت | LM2903DR |
|---|---|
| حجم فایل | 61.423 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 4 |
LM2903DR |
دانلود دیتاشیت |
|---|
سایر مستندات
LM193,293,393(A), 2903(V) Datasheet 45 pages
LM2903DR 12 pages
مشخصات فنی
- RoHS: true
- Category: Operational Amplifier/Comparator/Comparators
- Datasheet: Texas Instruments LM2903DR
- Output Type: Open Drain
- Supply Current: 2.5mA
- Supply Voltage: 2V~36V;1V~18V
- Number of Elements: 2
- Operating Temperature: -40°C~+125°C
- Input Bias Current (Ib): 0.25uA
- Input Offset Voltage (Vos): 7mV
- Input Hysteresis Voltage (Vhys): -
- Common Mode Rejection Ratio (CMRR): 88dB
- Package: SOP-8
- Manufacturer: Texas Instruments
- Current - Output (Typ): 20mA
- Series: -
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Hysteresis: -
- CMRR, PSRR (Typ): -
- Voltage - Input Offset (Max): 7mV @ 30V
- Supplier Device Package: 8-SOIC
- Type: Differential
- Propagation Delay (Max): -
- Current - Quiescent (Max): 2.5mA
- Base Part Number: LM2903
- Voltage - Supply, Single/Dual (±): 2V ~ 36V, ±1V ~ 18V
- Part Status: Active
- Packaging: Cut Tape (CT)
- Current - Input Bias (Max): 0.25µA @ 5V
- Mounting Type: Surface Mount
- detail: Comparator Differential CMOS, MOS, Open-Drain, TTL 8-SOIC
