دیتاشیت CM1231-02SO
مشخصات دیتاشیت
| نام دیتاشیت |
CM1231-02SO
|
| حجم فایل |
322.876
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
12
|
مشخصات
-
RoHS:
true
-
Category:
TVS/Fuse/Board Level Protection/ESD Protection Devices
-
Datasheet:
onsemi CM1231-02SO
-
Number of Lines:
2
-
Clamping Voltage@Ipp:
9V
-
Operating Temperature:
-40°C~+85°C@(Ta)
-
Breakdown Voltage (VBR):
-
-
Peak Pulse Power(Ppp)@8/20us:
-
-
Junction Capacitance(Cj)@1MHz:
-
-
Peak Pulse Current(Ipp)@8/20us:
1A@(8/20us)
-
Reverse Stand-Off Voltage (Vrwm):
5V
-
Package:
SOT-23-6
-
Manufacturer:
onsemi
-
Series:
XtremeESD™
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Type:
Steering (Rail to Rail)
-
Unidirectional Channels:
2
-
Voltage - Reverse Standoff (Typ):
5V
-
Voltage - Breakdown (Min):
-
-
Voltage - Clamping (Max) @ Ipp:
9V (Typ)
-
Current - Peak Pulse (10/1000µs):
1A (8/20µs)
-
Power - Peak Pulse:
-
-
Power Line Protection:
Yes
-
Applications:
General Purpose
-
Capacitance @ Frequency:
-
-
Mounting Type:
Surface Mount
-
Package / Case:
SOT-23-6
-
Supplier Device Package:
SOT-23-6
-
Base Part Number:
CM1231
