MBRS540T3G Datasheet
Datasheet specifications
| Datasheet's name | MBRS540T3G |
|---|---|
| File size | 84.176 KB |
| File type | |
| Number of pages | 5 |
Download Datasheet MBRS540T3G |
Download Datasheet |
|---|
Other documentations
MBRS/NRVBS540T3G Datasheet 5 pages
SMC Pkg Drawing 1 pages
Technical specifications
- RoHS: true
- Category: Diodes/Schottky Barrier Diodes (SBD)
- Datasheet: onsemi MBRS540T3G
- Reverse Voltage (Vr): 40V
- Forward Voltage (Vf@If): 500mV@5A
- Average Rectified Current (Io): 5A
- Package: SMC(DO-214AB)
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 40V
- Current - Average Rectified (Io): 5A
- Voltage - Forward (Vf) (Max) @ If: 500mV @ 5A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Current - Reverse Leakage @ Vr: 300µA @ 40V
- Capacitance @ Vr, F: -
- Mounting Type: Surface Mount
- Package / Case: DO-214AB, SMC
- Supplier Device Package: SMC
- Operating Temperature - Junction: -65°C ~ 150°C
- Base Part Number: MBRS540
