LM2575T-ADJ Datasheet
Datasheet specifications
| Datasheet's name | LM2575T-ADJ |
|---|---|
| File size | 6151.249 KB |
| File type | |
| Number of pages | 44 |
Download Datasheet LM2575T-ADJ |
Download Datasheet |
|---|
Other documentations
LM2575T-12 8 pages
LM2575 28 pages
Technical specifications
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Datasheet: HGSEMI LM2575T-ADJ
- Package: TO-220-5
- Manufacturer: HGSEMI
- Series: -
- Packaging: Tube
- Part Status: Obsolete
- Function: Step-Down
- Output Configuration: Positive
- Topology: Buck
- Output Type: Adjustable
- Number of Outputs: 1
- Voltage - Input (Min): 4.75V
- Voltage - Input (Max): 40V
- Voltage - Output (Min/Fixed): 1.23V
- Voltage - Output (Max): 37V
- Current - Output: 1A
- Frequency - Switching: 52kHz
- Synchronous Rectifier: No
- Operating Temperature: -40°C ~ 125°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-220-5
- Supplier Device Package: TO-220-5
- Base Part Number: LM2575
- detail: Buck Switching Regulator IC Positive Adjustable 1.23V 1 Output 1A TO-220-5
