دیتاشیت CD4081BE

CD4073B/81B/82B Types

مشخصات دیتاشیت

نام دیتاشیت CD4073B/81B/82B Types
حجم فایل 1821.286 کیلوبایت
نوع فایل pdf
تعداد صفحات 31

دانلود دیتاشیت CD4073B/81B/82B Types

CD4073B/81B/82B Types Datasheet

مشخصات

  • Supplier Device Package: 14-PDIP
  • Base Part Number: CD4081
  • Operating Temperature: -55°C ~ 125°C
  • Logic Type: AND Gate
  • Number of Circuits: 4
  • Packaging: Tube
  • Number of Inputs: 2
  • Current - Output High, Low: 3.4mA, 3.4mA
  • Manufacturer: Texas Instruments
  • Max Propagation Delay @ V, Max CL: 90ns @ 15V, 50pF
  • Features: -
  • Logic Level - High: 3.5V ~ 11V
  • Package / Case: 14-DIP (0.300", 7.62mm)
  • Current - Quiescent (Max): 1µA
  • Mounting Type: Through Hole
  • Part Status: Active
  • Series: 4000B
  • Voltage - Supply: 3V ~ 18V
  • Logic Level - Low: 1.5V ~ 4V
