دیتاشیت CD4014BE
مشخصات دیتاشیت
| نام دیتاشیت | CD4014B,21B Types |
|---|---|
| حجم فایل | 1597.516 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 29 |
دانلود دیتاشیت CD4014B,21B Types |
CD4014B,21B Types Datasheet |
|---|
مشخصات
- RoHS: true
- Series: 4000B
- Category: Logic ICs/Shifting Register
- Function: ParallelorSerialtoSerial
- Datasheet: Texas Instruments CD4014BE
- Output Type: Push-pull
- Supply Voltage: 3V~18V
- Number of Elements: 1
- Operating Temperature: -55°C~+125°C
- Number of Bits per Element: 8
- Package: DIP-16
- Manufacturer: Texas Instruments
- Supplier Device Package: 16-PDIP
- Part Status: Active
- Mounting Type: Through Hole
- Base Part Number: CD4014
- Packaging: Tube
- Package / Case: 16-DIP (0.300", 7.62mm)
- Voltage - Supply: 3V ~ 18V
- Logic Type: Shift Register
- detail: Shift Shift Register 1 Element 8 Bit 16-PDIP
