دیتاشیت ADS1230IPWR
مشخصات دیتاشیت
| نام دیتاشیت |
ADS1230
|
| حجم فایل |
1190.297
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
31
|
مشخصات
-
RoHS:
true
-
Category:
ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
-
Datasheet:
Texas Instruments ADS1230IPWR
-
Interface:
SPI
-
resolution:
20Bit
-
Supply Voltage:
2.7V~5.3V
-
number of channels:
1
-
sampling frequency:
80Hz
-
Operating Temperature:
-40°C~+85°C
-
Package:
TSSOP-16
-
Manufacturer:
Texas Instruments
-
Architecture:
Sigma-Delta
-
Sampling Rate (Per Second):
80
-
Series:
-
-
Voltage - Supply, Analog:
2.7V ~ 5.3V
-
Input Type:
Differential, Single Ended
-
Number of A/D Converters:
1
-
Number of Bits:
20
-
Voltage - Supply, Digital:
2.7V ~ 5.3V
-
Packaging:
Cut Tape (CT)
-
Reference Type:
External
-
Ratio - S/H:ADC:
-
-
Configuration:
PGA-ADC
-
Supplier Device Package:
16-TSSOP
-
Data Interface:
SPI
-
Base Part Number:
ADS1230
-
Features:
PGA
-
Number of Inputs:
1
-
Mounting Type:
Surface Mount
-
Part Status:
Active
-
Package / Case:
16-TSSOP (0.173", 4.40mm Width)
