دیتاشیت STW7NK90Z

STx(6,7)NK90Z(FP)

مشخصات دیتاشیت

نام دیتاشیت STx(6,7)NK90Z(FP)
حجم فایل 669.261 کیلوبایت
نوع فایل pdf
تعداد صفحات 26

دانلود دیتاشیت STx(6,7)NK90Z(FP)

STx(6,7)NK90Z(FP) Datasheet

مشخصات

  • Manufacturer: STMicroelectronics
  • Series: SuperMESH™
  • Packaging: Tube
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 900V
  • Current - Continuous Drain (Id) @ 25°C: 5.8A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 2Ohm @ 2.9A, 10V
  • Vgs(th) (Max) @ Id: 4.5V @ 100µA
  • Gate Charge (Qg) (Max) @ Vgs: 60.5nC @ 10V
  • Vgs (Max): ±30V
  • Input Capacitance (Ciss) (Max) @ Vds: 1350pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 140W (Tc)
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-247-3
  • Package / Case: TO-247-3
  • Base Part Number: STW7N
  • detail: N-Channel 900V 5.8A (Tc) 140W (Tc) Through Hole TO-247-3
