MUR1560 数据手册
其他文档
MUR1510(15,20,40,60) 8 pages
技术规格
- Manufacturer: ON Semiconductor
- Series: SWITCHMODE™
- Packaging: Tube
- Part Status: Obsolete
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 600V
- Current - Average Rectified (Io): 15A
- Voltage - Forward (Vf) (Max) @ If: 1.5V @ 15A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 60ns
- Current - Reverse Leakage @ Vr: 10µA @ 600V
- Capacitance @ Vr, F: -
- Mounting Type: Through Hole
- Package / Case: TO-220-2
- Supplier Device Package: TO-220AC
- Operating Temperature - Junction: -65°C ~ 175°C
- Base Part Number: MUR15
