دیتاشیت UC2843BD1R2G
مشخصات دیتاشیت
| نام دیتاشیت | UC384(2,3)B, UC284(2,3)B |
|---|---|
| حجم فایل | 418.788 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 22 |
دانلود دیتاشیت UC384(2,3)B, UC284(2,3)B |
UC384(2,3)B, UC284(2,3)B Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Controllers
- Datasheet: onsemi UC2843BD1R2G
- Package: SOIC-8
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Type: Transistor Driver
- Function: Step-Up, Step-Up/Step-Down
- Output Configuration: Positive
- Topology: Boost, Flyback
- Number of Outputs: 1
- Output Phases: 1
- Voltage - Supply (Vcc/Vdd): 7.6V ~ 30V
- Frequency - Switching: Up to 500kHz
- Duty Cycle (Max): 96%
- Synchronous Rectifier: No
- Clock Sync: No
- Serial Interfaces: -
- Control Features: Frequency Control
- Operating Temperature: -25°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 8-SOIC
- Base Part Number: UC284
