دیتاشیت TPS54335ADDAR

TPS54335A, TPS54336A Datasheet

مشخصات دیتاشیت

نام دیتاشیت TPS54335A, TPS54336A Datasheet
حجم فایل 3581.99 کیلوبایت
نوع فایل pdf
تعداد صفحات 57

دانلود دیتاشیت TPS54335A, TPS54336A Datasheet

TPS54335A, TPS54336A Datasheet Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/DC-DC Converters
  • Function: Step-down type
  • Topology: Step-down
  • Datasheet: Texas Instruments TPS54335ADDAR
  • Output Type: Adjustable
  • Input Voltage: 4.5V~28V
  • Output Voltage: 0.8V~24V
  • Number of Outputs: 1
  • Switching Frequency: 1.5MHz
  • Output Current (Max): 3A
  • Operating Temperature: -40°C~+150°C@(TJ)
  • Synchronous Rectification: Yes
  • Package: SOP-8-EP
  • Manufacturer: Texas Instruments
  • Frequency - Switching: 50kHz ~ 1.5MHz
  • Package / Case: 8-PowerSOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 8-SO PowerPad
  • Voltage - Output (Min/Fixed): 0.8V
  • Current - Output: 3A
  • Output Configuration: Positive
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Voltage - Output (Max): 24V
  • Series: -
  • Mounting Type: Surface Mount
  • Voltage - Input (Max): 28V
  • Base Part Number: TPS543
  • Voltage - Input (Min): 4.5V
  • Synchronous Rectifier: Yes
