- دیتاشیت SB540
SB540 دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | SB540 |
|---|---|
| حجم فایل | 68.667 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 2 |
دانلود دیتاشیت SB540 |
دانلود دیتاشیت |
|---|
سایر مستندات
SB520 - SB5100 5 pages
SB540 3 pages
مشخصات فنی
- RoHS: true
- Category: Diodes/Schottky Barrier Diodes (SBD)
- Datasheet: PANJIT International SB540
- Reverse Voltage (Vr): 40V
- Forward Voltage (Vf@If): 550mV@5A
- Average Rectified Current (Io): 5A
- Package: DO-27
- Manufacturer: PANJIT International
- Reverse Leakage Current (Ir): 500uA@40V
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 40V
- Current - Average Rectified (Io): 5A
- Voltage - Forward (Vf) (Max) @ If: 550mV @ 5A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Current - Reverse Leakage @ Vr: 500µA @ 40V
- Capacitance @ Vr, F: 500pF @ 4V, 1MHz
- Mounting Type: Through Hole
- Package / Case: DO-201AD, Axial
- Supplier Device Package: DO-201AD
- Operating Temperature - Junction: -55°C ~ 150°C
- Base Part Number: SB54
- detail: Diode Schottky 40V 5A Through Hole DO-201AD
