دیتاشیت TS5A21366RSER
مشخصات دیتاشیت
| نام دیتاشیت |
TS5A21366
|
| حجم فایل |
1334.388
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
35
|
مشخصات
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
-
Datasheet:
Texas Instruments TS5A21366RSER
-
Turn-on time:
72ns
-
Turn-off time:
318ns
-
Supply Voltage:
1.65V~5.5V
-
Switch Circuit:
SPST(SPST)-Normal Open
-
Number of Channels:
2
-
On-State Resistance (Max):
1Ω
-
Package:
QFN-8(1.5x1.5)
-
Manufacturer:
Texas Instruments
-
Channel Capacitance (CS(off), CD(off)):
19pF, 17pF
-
Channel-to-Channel Matching (ΔRon):
40mOhm
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Packaging:
Cut Tape (CT)
-
Multiplexer/Demultiplexer Circuit:
1:1
-
-3db Bandwidth:
260MHz
-
Charge Injection:
1.3pC
-
Current - Leakage (IS(off)) (Max):
10nA
-
Package / Case:
8-UFQFN
-
Voltage - Supply, Single (V+):
1.65V ~ 5.5V
-
Switch Time (Ton, Toff) (Max):
72ns, 318ns
-
Supplier Device Package:
8-UQFN (1.5x1.5)
-
Mounting Type:
Surface Mount
-
Base Part Number:
TS5A213
-
Voltage - Supply, Dual (V±):
-
-
Number of Circuits:
2
-
Crosstalk:
-98dB @ 1MHz
-
Part Status:
Active
-
Series:
-
