دیتاشیت L4940V5

L4940

مشخصات دیتاشیت

نام دیتاشیت L4940
حجم فایل 1123.752 کیلوبایت
نوع فایل pdf
تعداد صفحات 25

دانلود دیتاشیت L4940

L4940 Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: STMicroelectronics L4940V5
  • Output Type: Fixed
  • Output Current: 1.5A
  • Output Voltage: 5V
  • Dropout Voltage: 900mV@(1.5A)
  • Output Polarity: Positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 17V
  • Operating Temperature: -40°C~+150°C
  • Quiescent Current (Ground Current): 8mA
  • Power Supply Rejection Ratio (PSRR): 68dB@(120Hz)
  • Package: TO-220
  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Output Configuration: Positive
  • Number of Regulators: 1
  • Voltage - Input (Max): 17V
  • Voltage - Output (Min/Fixed): 5V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.9V @ 1.5A
  • Current - Output: 1.5A
  • Current - Quiescent (Iq): 8mA
  • Current - Supply (Max): 50mA
  • PSRR: 68dB (120Hz)
  • Control Features: -
  • Protection Features: Over Temperature, Reverse Polarity, Short Circuit
  • Mounting Type: Through Hole
  • Package / Case: TO-220-3
  • Supplier Device Package: TO-220AB
  • Base Part Number: L4940
  • detail: Linear Voltage Regulator IC 1 Output 1.5A TO-220AB
