دیتاشیت SN74HC244N

SN54HC244, SN74HC244

مشخصات دیتاشیت

نام دیتاشیت SN54HC244, SN74HC244
حجم فایل 1653.783 کیلوبایت
نوع فایل pdf
تعداد صفحات 34

دانلود دیتاشیت SN54HC244, SN74HC244

SN54HC244, SN74HC244 Datasheet

مشخصات

  • RoHS: true
  • Category: Logic ICs/Buffer/Driver/Transceiver
  • Datasheet: Texas Instruments SN74HC244N
  • Input type: -
  • output type: Tri-State
  • Logic Family: 74HC
  • Sink Current: 7.8mA
  • Source Current: 7.8mA
  • Supply Voltage: 2V~6V
  • Number of Elements: 2
  • Operating Temperature: -40°C~+85°C
  • Number of Bits per Element: 4
  • Package: DIP-20
  • Manufacturer: Texas Instruments
  • Voltage - Supply: 2V ~ 6V
  • Mounting Type: Through Hole
  • Packaging: Tube
  • Package / Case: 20-DIP (0.300", 7.62mm)
  • Part Status: Active
  • Current - Output High, Low: 7.8mA, 7.8mA
  • Series: 74HC
  • Supplier Device Package: 20-PDIP
  • Logic Type: Buffer, Non-Inverting
  • Base Part Number: SN74HC2
