دیتاشیت MOC3021M
مشخصات دیتاشیت
| نام دیتاشیت | MOC3010-12M, MOC3020-23M |
|---|---|
| حجم فایل | 350.56 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 12 |
دانلود دیتاشیت MOC3010-12M, MOC3020-23M |
MOC3010-12M, MOC3020-23M Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Optocoupler/LED/Digital Tube/Photoelectric Device/Optocouplers - Thyristor Signal Output
- SCR Type: Two-way thyristor
- Datasheet: UMW(Youtai Semiconductor Co., Ltd.) MOC3021M
- Forward Current: 60mA
- Forward Voltage: 1.18V
- Number of Outputs: 1
- Operating Temperature: -55°C~+100°C
- Zero Crossing Circuit: No
- Isolation Voltage(rms): 5000V
- Peak Off-state Voltage(Vdrm): 400V
- RMS On-State Current(It(rms)): 100mA
- Package: DIP-6
- Manufacturer: UMW(Youtai Semiconductor Co., Ltd.)
- Series: -
- Packaging: Tube
- Part Status: Active
- Output Type: Triac
- Number of Channels: 1
- Voltage - Isolation: 4170Vrms
- Voltage - Off State: 400V
- Static dV/dt (Min): -
- Current - LED Trigger (Ift) (Max): 15mA
- Current - Hold (Ih): 100µA (Typ)
- Turn On Time: -
- Voltage - Forward (Vf) (Typ): 1.15V
- Current - DC Forward (If) (Max): 60mA
- Mounting Type: Through Hole
- Package / Case: 6-DIP (0.300", 7.62mm)
- Supplier Device Package: 6-DIP
- Approval Agency: UL
- Base Part Number: MOC302
- detail: Optoisolator Triac Output 4170Vrms 1 Channel 6-DIP
