- UCx825 Datasheet
UCx825 Datasheet Datasheet
Datasheet specifications
| Datasheet's name | UCx825 Datasheet |
|---|---|
| File size | 1516.506 KB |
| File type | |
| Number of pages | 20 |
Download Datasheet UCx825 Datasheet |
Download Datasheet |
|---|
Other documentations
UC3825N 22 pages
Technical specifications
- RoHS: true
- Category: Power Supply Chip/DC-DC Controllers
- Function: boost converterType;Buck-boost type
- Topology: Boost;Flyback;Full-Bridge;Half-Bridge;Push-pull
- Datasheet: Texas Instruments UC2825N
- Input Voltage: 8.4V~30V
- Duty Cycle (Max): 80%
- Number of Outputs: 2
- Switching Frequency: 460kHz
- Operating Temperature: -40°C~+85°C@(TA)
- Synchronous Rectification: NO
- Package: PDIP-16
- Manufacturer: Texas Instruments
- Part Status: Active
- Package / Case: 16-DIP (0.300", 7.62mm)
- Packaging: Tube
- Frequency - Switching: 340kHz ~ 460kHz
- Supplier Device Package: 16-PDIP
- Serial Interfaces: -
- Synchronous Rectifier: No
- Clock Sync: No
- Mounting Type: Through Hole
- Output Configuration: Positive
- Base Part Number: UC282
- Series: -
- Output Type: Transistor Driver
- Control Features: Current Limit, Enable, Frequency Control, Ramp, Soft Start
- Output Phases: 1
- Voltage - Supply (Vcc/Vdd): 8.4V ~ 30V
- detail: Boost, Flyback, Forward Converter, Full-Bridge, Half-Bridge, Push-Pull Regulator Positive Output Step-Up, Step-Up/Step-Down DC-DC Controller IC 16-PDIP
