دیتاشیت CD4043BE
مشخصات دیتاشیت
| نام دیتاشیت | CD4043B,44B Types |
|---|---|
| حجم فایل | 2601.079 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 34 |
دانلود دیتاشیت CD4043B,44B Types |
CD4043B,44B Types Datasheet |
|---|
مشخصات
- RoHS: true
- Series: 4000B
- Category: Logic ICs/Latches
- Datasheet: Texas Instruments CD4043BE
- Logic Type: S-R Latch
- Output Type: Tri-State
- Sink Current: 6.8mA
- Source Current: 6.8mA
- Supply Voltage: 3V~18V
- Propagation Delay: 50ns
- OperatingTemperature: -55°C~+125°C
- Package: DIP-16
- Manufacturer: Texas Instruments
- Independent Circuits: 4
- Voltage - Supply: 3V ~ 18V
- Circuit: 1:1
- Operating Temperature: -55°C ~ 125°C
- Mounting Type: Through Hole
- Packaging: Tube
- Package / Case: 16-DIP (0.300", 7.62mm)
- Delay Time - Propagation: 50ns
- Part Status: Active
- Current - Output High, Low: 6.8mA, 6.8mA
- Supplier Device Package: 16-PDIP
- Base Part Number: CD4043
- detail: S-R Latch 4 Channel 1:1 IC Tri-State 16-PDIP
