TC442(3, 4, 5) Datasheet

TC442(3, 4, 5)

Datasheet specifications

Datasheet's name TC442(3, 4, 5)
File size 347.117 KB
File type pdf
Number of pages 20

Download Datasheet TC442(3, 4, 5)

Download Datasheet

Other documentations

TC4423CPA 20 pages

Technical specifications

  • RoHS: true
  • Category: Power Supply Chip/Gate Drive ICs
  • Datasheet: Microchip Tech TC4424CPA
  • Fall Time: 25ns
  • Load Type: MOSFET
  • Rise Time: 23ns
  • Supply Voltage: 4.5V~18V
  • Number of Drivers: 2
  • Driven Configuration: Low Side
  • Operating Temperature: 0°C~+150°C@(Tj)
  • Peak Output Current(sink): 3A
  • Peak Output Current(source): 3A
  • Package: PDIP-8
  • Manufacturer: Microchip Tech
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Channel Type: Independent
  • Gate Type: N-Channel, P-Channel MOSFET
  • Voltage - Supply: 4.5V ~ 18V
  • Logic Voltage - VIL, VIH: 0.8V, 2.4V
  • Current - Peak Output (Source, Sink): 3A, 3A
  • Input Type: Non-Inverting
  • Rise / Fall Time (Typ): 23ns, 25ns
  • Mounting Type: Through Hole
  • Package / Case: 8-DIP (0.300", 7.62mm)
  • Supplier Device Package: 8-PDIP
  • Base Part Number: TC4424
  • detail: Low-Side Gate Driver IC Non-Inverting 8-PDIP
